Toyota bZ4X FWD (MY22-24)

Available since June 2022

64.0 kWhUseable Battery

350 km *Real Range

183 Wh/km *Efficiency

Price

United Kingdom £42,995
The Netherlands €45,995
Germany €42,900

Available to Order

United Kingdom Since August 2022
The Netherlands Jul 2022 - Jul 2025
Germany Since June 2022
Prices shown are recommended retail prices for the specified countries and do not include any indirect incentives. Pricing and included options can differ by region and do not include any indirect incentives. Dates shown are order dates. Click on a country for more details.

Real Range Estimation between 250 - 515 km

City - Cold Weather * 345 km
Highway - Cold Weather * 250 km
Combined - Cold Weather * 295 km
City - Mild Weather * 515 km
Highway - Mild Weather * 320 km
Combined - Mild Weather * 400 km
Indication of real-world range in several situations. Cold weather: 'worst-case' based on -10°C and use of heating. Mild weather: 'best-case' based on 23°C and no use of A/C. For 'Highway' figures a constant speed of 110 km/h is assumed. The actual range will depend on speed, style of driving, weather and route conditions.
(Advertisement)

Long Distance Suitability
2 / 5

First Leg Distance 253 km
Charging Stop 0km
Second Leg Distance 131 km
Total Distance 384 km
First Leg Duration 2h 18min
Charging Stop 15 min
Second Leg Duration 1h 12min
Total Duration 3h 45min
Click here for the full analysis
The 'long distance suitability' is a 5-star rating that indicates how suitable a vehicle is for long trips. The rating is based on the 1-Stop Range: the total distance a vehicle can cover with one charging stop of 15 minutes.

Battery

Nominal Capacity 71.4 kWh
Battery Type Lithium-ion
Number of Cells 96
Architecture 400 V
Warranty Period No Data
Warranty Mileage No Data
Useable Capacity 64.0 kWh
Cathode Material NCM
Pack Configuration 96s1p
Nominal Voltage 355 V
Form Factor No Data
Name / Reference No Data

Charging

Home / Destination

Charge Port Type 2
Port Location Left Side - Front
Charge Power 6.6 kW AC
Charge Time (0->350 km) 11h30m
Charge Speed 31 km/h

Fast Charging

Charge Port CCS
Port Location Left Side - Front
Charge Power (max) 147 kW DC
Charge Power (10-80%) 100 kW DC
Charge Time (35->280 km) 28 min
Charge Speed 520 km/h
Autocharge Supported Yes

Plug & Charge

Plug & Charge Supported No
Supported Protocol -

Battery Preconditioning

Preconditioning Possible No
Automatically using Navigation No
Click here for all charging information
(Advertisement)

Performance

Acceleration 0 - 100 km/h 7.5 sec
Top Speed 160 km/h
Electric Range * 350 km
Total Power 150 kW (204 PS)
Total Torque 265 Nm
Drive Front

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L Supported No
Max. Output Power -
Exterior Outlet(s) -
Interior Outlet(s) -

Vehicle-to-Home (V2H)

V2H via AC Supported No
Max. Output Power -
V2H via DC Supported No
Max. Output Power -

Vehicle-to-Grid (V2G)

V2G via AC Supported No
Max. Output Power -
V2G via DC Supported No
Max. Output Power -

Energy Consumption

EVDB Real Range

Range * 350 km
Vehicle Consumption * 183 Wh/km
CO2 Emissions 0 g/km
Vehicle Fuel Equivalent * 2.1 l/100km

WLTP Ratings (TEL)

Range 516 km
Rated Consumption 144 Wh/km
Vehicle Consumption 124 Wh/km
CO2 Emissions 0 g/km
Rated Fuel Equivalent 1.6 l/100km
Vehicle Fuel Equivalent 1.4 l/100km

WLTP Ratings (TEH)

Range 442 km
Rated Consumption 167 Wh/km
Vehicle Consumption 145 Wh/km
CO2 Emissions 0 g/km
Rated Fuel Equivalent 1.9 l/100km
Vehicle Fuel Equivalent 1.6 l/100km
TEL = Test Energy Low | TEH = Test Energy High
Rated = official figures as published by manufacturer. Rated consumption and fuel equivalency figures include charging losses.
Vehicle = calculated battery energy consumption used by the vehicle for propulsion and on-board systems.

Real Energy Consumption Estimation between 124 - 256 Wh/km

City - Cold Weather * 186 Wh/km
Highway - Cold Weather * 256 Wh/km
Combined - Cold Weather * 217 Wh/km
City - Mild Weather * 124 Wh/km
Highway - Mild Weather * 200 Wh/km
Combined - Mild Weather * 160 Wh/km
Indication of real-world energy use in several situations. Cold weather: 'worst-case' based on -10°C and use of heating. Mild weather: 'best-case' based on 23°C and no use of A/C. For 'Highway' figures a constant speed of 110 km/h is assumed. The energy use will depend on speed, style of driving, climate and route conditions.
(Advertisement)

Safety (Euro NCAP)

Safety Rating
Adult Occupant 88%
Child Occupant 87%
Rating Year 2022
Vulnerable Road Users 79%
Safety Assist 91%
For more details on the safety rating of this vehicle, visit euroncap.com

Dimensions and Weight

Length 4690 mm
Width 1860 mm
Width with mirrors No Data
Height 1600 mm
Wheelbase 2850 mm
Weight Unladen (EU) 1970 kg
Gross Vehicle Weight (GVWR) 2465 kg
Max. Payload 570 kg
Cargo Volume 452 L
Cargo Volume Max 784 L
Cargo Volume Frunk No Data
Roof Load 75 kg
Tow Hitch Possible Yes
Towing Weight Unbraked 750 kg
Towing Weight Braked 750 kg
Vertical Load Max 75 kg

Miscellaneous

Seats 5 people
Isofix Yes, 2 seats
Turning Circle 11.4 m
Platform TMC E-TNGA
EV Dedicated Platform Yes
Car Body SUV
Segment JC - Medium
Roof Rails Yes
Heat pump (HP) Yes
HP Standard Equipment Yes
* = estimated value. Average energy consumption and range based on moderate drive style and climate. Real-life values may differ significantly. Pricing information might not be actual for some regions. No rights can be derived from the information on this site.

Home and Destination Charging (0 -> 100%)

Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the Toyota bZ4X FWD. Each option shows how fast the battery can be charged from empty to full.

Europe

Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the Toyota bZ4X FWD can be charged, but some modes of charging might not be widely available in certain countries.

Type 2 (Mennekes - IEC 62196)
Charging Point Max. Power Power Time Rate
Standard 6.6 kW On-Board Charger
Wall Plug (2.3 kW) 230V / 1x10A 2.3 kW 32h45m 11 km/h
1-phase 16A (3.7 kW) 230V / 1x16A 3.7 kW 20h30m 17 km/h
1-phase 32A (7.4 kW) 230V / 1x29A 6.6 kW † 11h30m 30 km/h
3-phase 16A (11 kW) 230V / 1x16A 3.7 kW † 20h30m 17 km/h
3-phase 32A (22 kW) 230V / 1x29A 6.6 kW † 11h30m 30 km/h
Optional 11.0kW On-Board Charger *
Wall Plug (2.3 kW) 230V / 1x10A 2.3 kW 32h45m 11 km/h
1-phase 16A (3.7 kW) 230V / 1x16A 3.7 kW 20h30m 17 km/h
1-phase 32A (7.4 kW) 230V / 1x32A 7.4 kW 10h15m 34 km/h
3-phase 16A (11 kW) 400V / 3x16A 11 kW 7 hours 50 km/h
3-phase 32A (22 kW) 400V / 3x16A 11 kW † 7 hours 50 km/h

† = Limited by on-board charger, vehicle cannot charge faster.

* = Optional in some countries, standard in others. Check local specifications for details.

(Advertisement)

Fast Charging (10 -> 80%)

Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the Toyota bZ4X FWD.

  • Max. Power: maximum power provided by charge point
  • Avg. Power: average power provided by charge point over a session from 10% to 80%
  • Time: time needed to charge from 10% to 80%
  • Rate: average charging speed over a session from 10% to 80%
Combined Charging System (CCS Combo 2)
Charging Point Max. Power Avg. Power Time Rate
CCS (50 kW DC) 48 kW † 46 kW † 62 min 230 km/h
CCS (150 kW DC) 147 kW † 100 kW † 28 min 520 km/h
Charge Curve

Data made available by Fastned
This vehicle supports Autocharge
This vehicle does not support Plug & Charge

† = Limited by charging capabilities of vehicle

Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.

Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.

Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.

Toyota Claimed Specifications

The table below shows the claimed specifications from the manufacturer for charging the Toyota bZ4X FWD. The specifications can differ from the table above for a variety of reasons. If real-world charge tests are available, these differences can be signifcant. If no real-world tests are available, the table above will be based on the manufacturer specifications as per the table below.

  • Max. Power: maximum charge power during charging session
  • Charge From: battery percentage (% SoC) where charging session is started
  • Charge To: battery percentage (% SoC) where charging session is ended
  • Time: time needed for charging session
Toyota Claimed Specifications
Max. Power Charge From Charge To Time
150 kW 10 % 80 % 30 min

Long Distance Suitability

How suitable an electric car is for long trips depends not only on the range. How quickly the car can charge plays an almost equally important role. Whether an EV is suitable for long trips depends on the battery capacity, efficiency, and fast charging capability.

To easily compare cars among each other, a benchmark has been established that combines these factors into the total distance a vehicle can cover with one 15-minute charging stop: the '1-Stop Range'. Based on the 1-Stop Range, the 5-star rating is determined. The result of the benchmark is shown in the graph below.

1-Stop Range

+

5-Star Rating

+

Revision of Rating

+

Toyota bZ4X FWD
2 / 5

0
1
2
3
4
5
288 km
2h 37min
15 min
150 km
1h 22min
253 km
2h 18min
15 min
131 km
1h 12min
384 km (3h 45min)
225 km
2h 3min
15 min
117 km
1h 4min
342 km (3h 22min)
0 km
100
200
300
400
500
600
700
800
Mild Weather
438 km 1-Stop Range
Average Conditions
384 km 1-Stop Range
Cold Weather
342 km 1-Stop Range
