Mercedes-Benz EQB 250+

Available since October 2023

70.5 kWhUseable Battery

415 km *Real Range

170 Wh/km *Efficiency

Price

United Kingdom	£52,800
The Netherlands	€54,966
Germany	€53,514

Available to Order

United Kingdom	Since December 2023
The Netherlands	Since October 2023
Germany	Since October 2023

Prices shown are recommended retail prices for the specified countries and do not include any indirect incentives. Pricing and included options can differ by region and do not include any indirect incentives. Dates shown are order dates. Click on a country for more details.

Real Range Estimation between 300 - 610 km

City - Cold Weather *	405 km
Highway - Cold Weather *	300 km
Combined - Cold Weather *	350 km

City - Mild Weather *	610 km
Highway - Mild Weather *	385 km
Combined - Mild Weather *	480 km

Indication of real-world range in several situations. Cold weather: 'worst-case' based on -10°C and use of heating. Mild weather: 'best-case' based on 23°C and no use of A/C. For 'Highway' figures a constant speed of 110 km/h is assumed. The actual range will depend on speed, style of driving, weather and route conditions.

(Advertisement)

Long Distance Suitability
2.5 / 5

First Leg Distance	304 km
Charging Stop	0km
Second Leg Distance	110 km
Total Distance	414 km

First Leg Duration	2h 46min
Charging Stop	15 min
Second Leg Duration	1h 0min
Total Duration	4h 1min

Click here for the full analysis

The 'long distance suitability' is a 5-star rating that indicates how suitable a vehicle is for long trips. The rating is based on the 1-Stop Range: the total distance a vehicle can cover with one charging stop of 15 minutes.

Battery

Nominal Capacity	73.9 kWh
Battery Type	Lithium-ion
Number of Cells	No Data
Architecture	400 V
Warranty Period	8 years
Warranty Mileage	160,000 km

Useable Capacity	70.5 kWh
Cathode Material	No Data
Pack Configuration	No Data
Nominal Voltage	No Data
Form Factor	No Data
Name / Reference	No Data

Charging

Home / Destination

Charge Port	Type 2
Port Location	Right Side - Rear
Charge Power	11 kW AC

Charge Time (0->415 km)	7h45m
Charge Speed	55 km/h

Fast Charging

Charge Port	CCS
Port Location	Right Side - Rear
Charge Power (max) *	102 kW DC
Charge Power (10-80%) *	90 kW DC

Charge Time (41->332 km) *	35 min
Charge Speed *	490 km/h
Autocharge Supported	Yes

Plug & Charge

Plug & Charge Supported

Yes

Supported Protocol

ISO 15118-2

Battery Preconditioning

Preconditioning Possible

Yes

Automatically using Navigation

Yes

Click here for all charging information

(Advertisement)

Performance

Acceleration 0 - 100 km/h	8.9 sec
Top Speed	160 km/h
Electric Range *	415 km

Total Power	140 kW (190 PS)
Total Torque	385 Nm
Drive	Front

Bidirectional Charging (V2X / BPT)

Vehicle-to-Load (V2L)

V2L Supported	No
Max. Output Power	-

Exterior Outlet(s)	-
Interior Outlet(s)	-

Vehicle-to-Home (V2H)

V2H via AC Supported	No
Max. Output Power	-

V2H via DC Supported	No
Max. Output Power	-

Vehicle-to-Grid (V2G)

V2G via AC Supported	No
Max. Output Power	-

V2G via DC Supported	No
Max. Output Power	-

Energy Consumption

EVDB Real Range

Range *	415 km
Vehicle Consumption *	170 Wh/km

CO2 Emissions	0 g/km
Vehicle Fuel Equivalent *	1.9 l/100km

WLTP Ratings (TEL)

Range	536 km
Rated Consumption	152 Wh/km
Vehicle Consumption	132 Wh/km

CO2 Emissions	0 g/km
Rated Fuel Equivalent	1.7 l/100km
Vehicle Fuel Equivalent	1.5 l/100km

WLTP Ratings (TEH)

Range	463 km
Rated Consumption	175 Wh/km
Vehicle Consumption	152 Wh/km

CO2 Emissions	0 g/km
Rated Fuel Equivalent	2.0 l/100km
Vehicle Fuel Equivalent	1.7 l/100km

TEL = Test Energy Low | TEH = Test Energy High
Rated = official figures as published by manufacturer. Rated consumption and fuel equivalency figures include charging losses.
Vehicle = calculated battery energy consumption used by the vehicle for propulsion and on-board systems.

Real Energy Consumption Estimation between 116 - 235 Wh/km

City - Cold Weather *	174 Wh/km
Highway - Cold Weather *	235 Wh/km
Combined - Cold Weather *	201 Wh/km

City - Mild Weather *	116 Wh/km
Highway - Mild Weather *	183 Wh/km
Combined - Mild Weather *	147 Wh/km

Indication of real-world energy use in several situations. Cold weather: 'worst-case' based on -10°C and use of heating. Mild weather: 'best-case' based on 23°C and no use of A/C. For 'Highway' figures a constant speed of 110 km/h is assumed. The energy use will depend on speed, style of driving, climate and route conditions.

(Advertisement)

Dimensions and Weight

Length	4684 mm
Width	1834 mm
Width with mirrors	2020 mm
Height	1667 mm
Wheelbase	2829 mm
Weight Unladen (EU)	2105 kg
Gross Vehicle Weight (GVWR)	2540 kg
Max. Payload	510 kg

Cargo Volume	495 L
Cargo Volume Max	1710 L
Cargo Volume Frunk	0 L
Roof Load	75 kg
Tow Hitch Possible	Yes
Towing Weight Unbraked	750 kg
Towing Weight Braked	1400 kg
Vertical Load Max	80 kg

Miscellaneous

Seats	7 people
Isofix	Yes, 4 seats
Turning Circle	11.7 m
Platform	DAIMLER MFA2
EV Dedicated Platform	No

Car Body	SUV
Segment	JC - Medium
Roof Rails	Yes
Heat pump (HP)	Yes
HP Standard Equipment	Yes

* = estimated value. Average energy consumption and range based on moderate drive style and climate. Real-life values may differ significantly. Pricing information might not be actual for some regions. No rights can be derived from the information on this site.

Home and Destination Charging (0 -> 100%)

Charging is possible by using a regular wall plug or a charging station. Public charging is always done through a charging station. How fast the EV can charge depends on the charging station (EVSE) used and the maximum charging capacity of the EV. The table below shows all possible options for charging the Mercedes-Benz EQB 250+. Each option shows how fast the battery can be charged from empty to full.

Europe

Charging an EV in Europe differs by country. Some European countries primarily use 1-phase connections to the grid, while other countries are almost exclusively using a 3-phase connection. The table below shows all possible ways the Mercedes-Benz EQB 250+ can be charged, but some modes of charging might not be widely available in certain countries.

Type 2 (Mennekes - IEC 62196)

Charging Point	Max. Power	Power	Time	Rate
Standard 11.0 kW On-Board Charger
Wall Plug (2.3 kW)	230V / 1x10A	2.3 kW	36h15m	11 km/h
1-phase 16A (3.7 kW)	230V / 1x16A	3.7 kW	22h30m	18 km/h
1-phase 32A (7.4 kW)	230V / 1x32A	7.4 kW	11h15m	37 km/h
3-phase 16A (11 kW)	400V / 3x16A	11 kW	7h45m	54 km/h
3-phase 32A (22 kW)	400V / 3x16A	11 kW †	7h45m	54 km/h
Optional 22.0kW On-Board Charger
Wall Plug (2.3 kW)	230V / 1x10A	2.3 kW	36h15m	11 km/h
1-phase 16A (3.7 kW)	230V / 1x16A	3.7 kW	22h30m	18 km/h
1-phase 32A (7.4 kW)	230V / 1x32A	7.4 kW	11h15m	37 km/h
3-phase 16A (11 kW)	400V / 3x16A	11 kW	7h45m	54 km/h
3-phase 32A (22 kW)	400V / 3x32A	22 kW †	3h45m	110 km/h

† = Limited by on-board charger, vehicle cannot charge faster.

(Advertisement)

Fast Charging (10 -> 80%)

Rapid charging enables longer journeys by adding as much range as possible in the shortest amount of time. Charging power will decrease significantly after 80% state-of-charge has been reached. A typical rapid charge therefore rarely exceeds 80% SoC. The rapid charge rate of an EV depends on the charger used and the maximum charging power the EV can handle. The table below shows all details for rapid charging the Mercedes-Benz EQB 250+.

Mercedes-Benz has not released details about rapid charging the EQB. The information below is based on estimated values of the most likely rapid charging capabilities.

Max. Power: maximum power provided by charge point
Avg. Power: average power provided by charge point over a session from 10% to 80%
Time: time needed to charge from 10% to 80%
Rate: average charging speed over a session from 10% to 80%

Combined Charging System (CCS Combo 2)

Charging Point	Max. Power	Avg. Power	Time	Rate
CCS (50 kW DC)	50 kW	45 kW †	69 min	250 km/h
CCS (100 kW DC)	100 kW	85 kW †	37 min	470 km/h
CCS (150 kW DC)	102 kW †	90 kW †	35 min	490 km/h

This vehicle supports Autocharge
This vehicle supports Plug & Charge

† = Limited by charging capabilities of vehicle

Autocharge: allows for automatic initiation of a charging session at supported CCS charging stations.

Plug & Charge: allows for automatic initiation of a charging session at supported CCS charging stations in accordance with ISO 15118.

Actual charging rates may differ from data shown due to factors like outside temperature, state of the battery and driving style.

Mercedes-Benz Claimed Specifications

The table below shows the claimed specifications from the manufacturer for charging the Mercedes-Benz EQB 250+. The specifications can differ from the table above for a variety of reasons. If real-world charge tests are available, these differences can be signifcant. If no real-world tests are available, the table above will be based on the manufacturer specifications as per the table below.

Max. Power: maximum charge power during charging session
Charge From: battery percentage (% SoC) where charging session is started
Charge To: battery percentage (% SoC) where charging session is ended
Time: time needed for charging session

Mercedes-Benz Claimed Specifications

Max. Power	Charge From	Charge To	Time
100 kW	10 %	80 %	35 min

Long Distance Suitability

How suitable an electric car is for long trips depends not only on the range. How quickly the car can charge plays an almost equally important role. Whether an EV is suitable for long trips depends on the battery capacity, efficiency, and fast charging capability.

To easily compare cars among each other, a benchmark has been established that combines these factors into the total distance a vehicle can cover with one 15-minute charging stop: the '1-Stop Range'. Based on the 1-Stop Range, the 5-star rating is determined. The result of the benchmark is shown in the graph below.

1-Stop Range

5-Star Rating

The 1-Stop Range describes the distance the vehicle can cover with one 15-minute charging stop. To clearly show the impact of temperature, the 1-Stop Range is determined for three weather conditions. These weather conditions are identical to those in the Real Range benchmark. The 1-Stop Range under average conditions determines the number of stars awarded. The star rating provides a quick way to assess whether a car is suitable for long trips compared to other cars.

Assignment of Stars in 2025

0	less than 200 km
1	from 200 km to 325 km
2	from 325 km to 450 km
3	from 450 km to 575 km
4	from 575 km to 700 km
5	more than 700 km

Vehicles with a result between these threshold values receive a rating based on a linear scale. Half stars are possible.

Revision of Rating
